Radiated NEMP Simulator
Radiated NEMP(Nuclear EMP) Simulator is used to simulate EMP signal which is reached on the earth surface by the nuclear
weapon explodes at high-altitude(HEMP). NEMP Simulator can be used for EMP radiation immunity test for various electronic
devices or systems by artificially creating EMP environment.
Our NEMP Simulator has been developed to allow testing of electronic device that is within 15cm, 50cm and 1m,
respectively and it is satisfied MIL-STD-461 RS105 test requirements.
-
-
NEMP-DCG-025KV
Small sized NEMP Simulator
E-field Polarity: Positive(+), Negative(-)
E-field Strength Range: 5kV/m~50kV/m or More
Test Area Volume (LxWxH): 15cm x 15cm x 15cm
Dimension (LxWxH): 2.3m x 0.8m x 0.6m
-
-
NEMP-DCG-100KV
Middle sized NEMP Simulator
E-field Polarity: Positive(+), Negative(-)
E-field Strength Range: 5kV/m~50kV/m or More
Test Area Volume (LxWxH): 50cm x 50cm x 50cm
Dimension (LxWxH): 7m x 2.5m x 1.5m
